SELF-PROPELLED SCISSOR LIFT PLATFORM CFPT0608
| Model | CFPT0608 |
| Load capacities | 450Kg |
| Load capacities of extended platform | 113Kg |
| Maximum number of workers | 2 |
| Working height A | 8m |
| Maximum platform height B | 6m |
| Length of the whole machine C | 2480mm |
| Overall width D | 1190mm |
| Overall height (guardrail unfolded) | 2200mm |
| Overall height (guardrail folded) E | 1660mm |
| Platform size F | 2.27×1.12m |
| Platform extension size G | 900mm |
| Minimum ground clearance (stowed) | 100mm |
| Minimum ground clearance (raised) | 19mm |
| Wheelbase | 1895mm |
| Minimum turning radius (inner wheel) | 0m |
| Minimum turning radius (outer wheel) | 2.2m |
| Lifting motor | 24V/3.3Kw |
| Machine running speed (stowed) | 3.5Km/h |
| Machine running speed (raised) | 0.8Km/h |
| Rising/descending speed | 24/34sec |
| Batteries | 4×6V/225Ah |
| Charger | 24V/25A |
| Gradeability | 25% |
| Max. working slope | 1.5°/3° |
| Tyre | Φ381×127 |
| Overall weight | 2170Kg |
1.Is SITC a manufacture or trading company ?
SITS is a group company , include five middle-sized factory ,one high technology developer company and a professional internation trade company. Supply from design — production — publicity — sell –after sell work all the line service team .
2.What’s the main products of SITC ?
SITC mainly support construction machinery , such as loader , skid loader , excavator , mixer , concrete pump , road roller , crane and etc.
3.How long is the warranty period ?
Normally , SITC products have one year guarantee period .
4.What is the MOQ ?
One set .
5.What’s the policy for the agents ?
For agents ,SITC supply the dealer price for their area , and help to do advertising in their area , some exhibitions in agent area also be supplied . Each year , SITC service engineer will go to the agents company to help them tread the technical questions.
