I. Core Power and Transmission System
Equipped with a Weichai 490 diesel engine, its low-speed, high-torque characteristics are suitable for complex working conditions. Rated power is matched with dual high- and low-speed torque converters and a continuously variable transmission (CVT). Low-speed gears enhance traction on muddy/steep slopes, while high-speed gears improve efficiency on flat ground. Actual transmission efficiency exceeds 85%, with torque output speed 300 rpm lower than similar Volvo models, resulting in earlier peak torque release.
II. Chassis and Braking System
Utilizing heavy-duty cast steel wheel-side reduction axles, paired with 23.5-16 herringbone tires, it achieves 2.6 times torque amplification, improving off-road capability on soft ground by 40%. Dual-pump air brakes have a response time of 0.3 seconds, and the four-wheel disc brakes exhibit excellent heat fade resistance, with only a 5% increase in distance after 10 consecutive braking cycles. Note that overloading may cause wear on the wheel-side reduction axle gears.
III. Humanized Configuration and Safety Design
The fully enclosed cab is equipped with an aviation-grade shock-absorbing seat, filtering 90% of ground vibrations. The single-lever operating system reduces the learning curve by 30%, and the dual-circuit braking system has been verified according to GB/T 35205-2017 standards, maintaining 50% braking force even in the event of single-circuit failure. Simulated collision tests show stable posture during emergency braking at 30km/h.
IV. Typical Working Condition Adaptability: In a construction site, the hydraulic system oil temperature was controlled below 85℃ while continuously transporting 5 tons of prefabricated components for 12 hours; in logistics scenarios, a 98% pallet compatibility rate was achieved; in mining tests, the 265 torque converter maintained stable power output even under a full load of 10 tons, verifying the power redundancy design.
Purchase Recommendations:
1. Prioritize the density of local service outlets, as this affects after-sales response time;
2. It is recommended to allow a 20% margin for continuous operation with the rated load;
3. In cold regions, confirm the low-temperature start configuration; a one-time ignition success device can be selected for environments as low as -25℃.
This model strikes a balance between power matching, off-road performance and handling comfort, and its quality performance meets the technical standards of medium-sized off-road forklifts, making it a practical choice for small and medium-sized enterprises with limited budgets and multi-terrain operations.
